CX16/24 Cutting Plotter
- Metal body.
- Camera for auto contour cutting.
- Fully adjustable pinch feed assembly.
- Multi-colored LED lighting.
- Laser engraving (optional).
Product Description
1. A highly advanced sensor that catches the command in no time without any complex process while working or providing commands.
2. For cutting small, light, and medium-small materials, it comes with 800G cutting force for smooth and glitch-free cutting.
3. Follow-back command function saves your time by preventing repeated commands for various materials.
4. Designed with an industrial-grade metal body that ensures long durability while giving a classic, shiny look and strong build.
Specifications
| Product | SKYCUT CX-24 |
|---|---|
| Max Media Width | 720mm |
| Max Cutting Width | 610mm |
| Max Contour Cutting Width | 570mm |
| Cutting Precision | 0.01mm |
| Repeat Precision | 0.082mm |
| Max Moving Speed | 700 mm/s |
| Max Cutting Speed | 600 mm/s |
| Max Force | 800g |
| Connector Interface | U-disk / WIFI / USB Cable |
| Power | < 100W |
| Working Environment | +5°C - +35°C |
| Packing Size | 730×330×330mm |
| Packing Gross Weight | appx 14kg |
Product Uses
Cutting Tools
All products come with capsule-type cutting tubes that offer stability, accuracy, and speed for smooth alignment and cutting.
Cutting Blades
We offer various blade angles—30°, 45°, and 60°—suitable for all cutter sizes, from compact models to industrial machines.
Drawing Pen Kit with Mat
Skycut provides a drawing pen kit and cutting mat for enhanced grip and precision. The D series includes two pens and a cutting mat.
Multi-function Cables
All Skycut products include USB, power cables, and adapters tailored to each cutter's specifications and power needs.
