skycut F3550 PRO Flatbed Cutting Plotter
- Professional compact flatbed plotter designed for high-precision cutting, creasing, and sample production.
- Equipped with an upgraded, larger touch screen for smoother and intuitive operation.
- Multi-language interface suitable for all regions and operators.
- Enhanced vacuum system for stable media holding during continuous production.
- Dual independent heads for faster and more efficient workflow.
Product Description
PRO-series upgraded control system with higher stability, improved processing accuracy, and enhanced performance.
RE-CUT function allows repeated cutting without reloading or resending the job.
Robust full-metal body offering durability, vibration-free operation, and long-term stability.
Dual independent heads for simultaneous cutting and creasing with professional-grade precision.
Specifications
| Product | SKYCUT F3550 FLATBED PLOTTER |
|---|---|
| Acceptable Media Size | 350 × 500 mm |
| Max Cutting Size | 350 × 500 mm |
| Work Mode | Vacuum Adsorbing |
| Control Panel | 5 inch Large Touch Screen |
| Heads / Tools | Dual Independent Heads |
| Cutting Precision | 0.01 mm |
| Repeat Precision | 0.03 mm |
| Max. Moving Speed | 1200 mm/s |
| Max. Force | 2000 g |
| Connector Interface | USB / WiFi / USB Cable |
| Power | < 100W |
| Working Environment | +5°C – +35°C |
| Packing Size | 940 × 690 × 290 mm |
| Packing Gross Weight | 80 kg |
| Floor Stand | Yes |
Product Uses
Camera for Auto Contour Cutting
High-resolution camera ensures precise Auto Print & Cut alignment, ideal for labels and packaging samples.
Large Touch Screen Menu
Bigger and faster touch screen compared to ECO variant for improved controls and user experience.
Dual Independent Head
Allows cutting and creasing without tool change, boosting production speed and accuracy.
Multi-interface
Supports USB cable, WiFi, and U-disk input, making workflow flexible and efficient.
